Xerox 8825 - Page 85

01/02
4-17
8825/8830 Printer
REP 7.10A
Repairs and Adjustments
2. (Figure 1): Remove the Lower Media Roll Heater.
Figure 1 Removing the Lower Media Roll Heater
2
Remove the screw
1
Disconnect
the connector
3
Remove the Lower
Media Roll Heater
