A-24 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Reference
NVM Settings - Write Used for changing the settings for internal
data of the printer.
This operation is prohibited since it can
damage the internal data.
NVM Settings - Read Used for confirming the internal data of the
printer.
NVM Settings - Save NVM to ESS Saves the internal data of the MCU Board to
the Image Processor Board. This is used when
the MCU Board needs to be replaced
Settings - Load NVM from ESS Loads the internal data saved via NVM
Settings - SaveNVM to ESS to the new MCU
Board.
Print Info
Config Page The current version of software and the
configuration of the printer can be confirmed
by executing this test. Click the Config Page
button to print the “Config Page”.
Print Settings The service tag, printing count value and
error count value can be confirmed by
executing this test. Click the Print Settings
button to print the “Print Settings” page.
Installation Set Displays values of the printer’s counters and
sets service tags.
To apply changes, click the Apply New
Settings button, or the Restart printer to
apply new settings button.
Printer Serial Number Serial number of the printer.
Pixel Counter Pixel count values of colors Y/M/C/K (read
only).
Tone Correction Specifies whether or not tone correction is
performed.
When the checkmark is placed in the
checkbox, tone correction is performed.
Configuration The use of “Configuration” is prohibited since
it is a tool for design development.
Print Counter Displays the respective counter values in the
master NVM and backup NVM (read only).
ESS NVM Init Initializes the NVM of the Image Processor
Board.
JOB LOG Init Initializes the print job history.
Apply New Settings This button should be clicked to move to any
other setting menu from the current menu in
operation.
NOTE After completion of all operations the Restart
printer to apply new settings button should be
clicked without exceptions.
Test Procedure
