Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only A-25
Reference
Restart printer to apply new
settings
Click this button when ready to apply your
changes to the settings.
The restart of a printer is required in order to
confirm this setup.
Test Print Print an internal test pattern of the printer. If
a paper jam or paper empty error occurs
during the print, the test waits until they are
resolved.
Paper Size Sets the paper size in which the test print is
printed.
Pitch Configuration Chart Allows you to check the print for any regular
lines or toner spots when encountering print
quality problems.
From the difference in the interval of regular
lines or spots, you can determine the parts
that have caused the trouble.
MQ Chart Prints charts to check for binding in A4 or
Letter.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
TestPatASIC[IOT] Prints the LED Driver Board built-in test
pattern.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
TestPatLPHY[IOT] Prints the LPH Y built-in test pattern.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
TestPatLPHM[IOT] Prints the LPH M built-in test pattern.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
TestPatLPHC[IOT] Prints the LPH C built-in test pattern.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
TestPatLPHK[IOT] Prints the LPH C built-in test pattern.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
Grid 2 Prints the ESS built-in grid pattern.
When a print quality problem occurs, this test
identifies the problem as printer-related or
otherwise.
Test Procedure
