CS1D Operating Manual (Basic Operation)
80
Delay settings
You can use the DELAY section of the SELECTED OUTPUT CHANNEL block to delay the output signal of a desired
output channel by a fixed time. For example, this provides a convenient way to compensate between speaker systems that
are located at a distance from each other.
[Procedure]
1. Use the [SEL] switches of the MIX OUTPUT block,
MATRIX OUTPUT block, or STEREO OUTPUT
block to select the output channel that you wish to
control.
2. In the DELAY section of the SELECTED OUTPUT
CHANNEL block, turn on the DELAY [ON] switch.
The switch LED will light, and the delay function will
be enabled for that channel.
3. Use the DELAY [TIME] encoder to specify the delay
time.
The delay time can be set in the range of 0–1000
msec.
Hint
Even for the STEREO A/B channels or for a paired
MIX/MATRIX channel, the delay settings must be
made independently. Select each channel in turn,
and make settings individually.
TIME
ON
msec
DELAY
SELECTED OUTPUT
CHANNEL block
DELAY [ON] switch
DELAY [TIME]
encoder
