Digital Input & Output Characteristics
INPUT/OUTPUT
TERMINALS
FORMAT LEVEL
CONNECTOR
TYPE QUANTITY
DIGITAL I/O
ENGINE A1, A2
ENGINE B1, B2
CONSOLE 1, 2
— RS422 D-SUB Half Pitch Connector 68P
(Female)
6
2-TRACK IN DIGITAL
AES/EBU 1-6
AES/EBU RS422 XLR-3-31 type Connector 6
2-TRACK IN DIGITAL
COAXIAL 1-2
IEC60958 0.5Vpp/75Ω RCA Phono JACK 2
STEREO OUT DIGITAL
AES/EBU A, B
AES/EBU RS422 XLR-3-32 type Connector 2
STEREO OUT DIGITAL
COAXIAL A, B
IEC60958 0.5Vpp/75Ω RCA Phono JACK 2
WORD CLOCK IN — TTL/75Ω (ON/OFF) BNC Connector 1
WORD CLOCK OUT — TTL/75Ω BNC Connector 1
SVGA OUT SVGA 2Vpp High density D-sub 15pin Con-
nector (Female)
1
KEYBOARD PS2 TTL Mini DIN 6pin Connector 2
MOUSE PS2 TTL Mini DIN 6pin Connector 2
NUMKEY PS2 TTL Mini DIN 6pin Connector 1
REMOTE RS-422 — RS422 D-sub 9pin Connector (Female) 1
MIDI IN, OUT, THRU MIDI — DIN 5pin Connector 3
TIME CODE IN SMPTE Nominal –10dB/
10kΩ
XLR-3-31 type Connector 1
GPI — C-MOS IN,
Open collector out
D-SUB 25pin Connector
(Female)
1
PC CONTROL USB — 0V - 3.3V B Type USB Connector 1
PC CONTROL RS-232-C — RS-232-C D-SUB 9pin Connector (Male) 1
CONTROL I/O
ENGINE A
1IN, 1OUT, 2IN, 2OUT
ENGINE B
1IN, 1OUT, 2IN, 2OUT
CONSOLE
1IN, 1OUT, 2IN, 2OUT
— –0.225V - –1.825V
/50Ω
BNC Connector 12
DC POWER INPUT — DC 60V KN-27-31S 27pin (Female) 2
