Yamaha CS1D - Analog Input Characteristics; Analog Output Characteristics

Analog Input Characteristics
65
METER BRIDGE BLOCK
DISPLAY BLOCK
Analog Input Characteristics
Analog Output Characteristics
8 digits 7 segment LED TIME CODE
3 digits 7 segment LED SCENE MEMORY NUMBER
16 digits 5 x 7 dot LED SCENE MEMORY NAME
LEDs SCENE MEMORY CURRENT, SCENE MEMORY PREVIEW
MIX OUT 1-24 meter 21 elements
MIX OUT 25-48 / MATRIX OUT 1-24 meter 21 elements
STEREO A L, R meter 21 elements
STEREO B L, R meter 21 elements
CUE L, R meter 21 elements
DISPLAY 800 x 600 dots COLOR GRAPHIC LCD w/ backlight
Analog Rotary Potentiometer BRIGHTNESS
Input Terminals GAIN
Actual Load
Impedance
For Use With
Nominal
Input level
Connector
Nominal Max. before clip
TALKBACK IN
1, 2
*1
*1. AD converters are 24bit linear, 128 times oversampling.
+48V DC (phantom power) is individually supplied to each TALKBACK connectors via 6.8kΩ resistors.
–44dB
3kΩ
50-600Ω Mics
& 600Ω Lines
–44dB (4.89mV) –30dB (24.5mV)
XLR-3-31 type
(Balanced)
*2
*2. Balanced (1= GND, 2= HOT, 3= COLD)
+10dB +10dB (2.45V) +24dB (12.3V)
2-TRACK IN
ANALOG 1, 2
*3
*3. AD converters are 24bit linear +4bit floating, 128 times oversampling.
• 0dB= 0.775Vrms, 0dBV= 1Vrms.
— 10kΩ 600Ω Lines +10dB (2.45V) +24dB (12.3V)
XLR-3-31 type
(Balanced)
Input Terminals
Actual Load
Impedance
For Use With
Nominal
Input level
Connector
Nominal Max. before clip
MONITOR OUT A, B 150Ω 600Ω Lines +10dB (2.45V) +24dB (12.3V)
XLR-3-32 type
(Balanced)
*1
*1. Balanced (1= GND, 2= HOT, 3= COLD)
CUE OUT 150Ω 600Ω Lines +10dB (2.45V) +24dB (12.3V)
XLR-3-32 type
(Balanced)
*1
PHONES A1, B1 15Ω
8Ω Phones 75mW 150mW
Stereo Phone Jack
(Unbalanced)
*2
*2. Unbalanced (Tip= LEFT, Ring= RIGHT, Sleeve= GND)
• 0dB= 0.775Vrms, 0dBV= 1Vrms.
• DA converters are 24bit linear, 128 times oversampling.
40Ω Phones 65mW 150mW
PHONES A2, B2 15Ω
8Ω Phones 75mW 150mW
Stereo Phone Jack
(Unbalanced)
*2
40Ω Phones 65mW 150mW
