IN HA/INSERT (Input head amp/insert) functions
131
IN PATCHIN HA/INSERTIN EQ
IN GATE/COMP
IN DELAYIN DCA/MUTE
PAN/ROUTING
IN CH VIEW
IN HA/INSERT (Input head amp/insert) functions
Settings for the head amp/phase section of the input unit
CH 1-24 – CH 73-96 / ST IN 1-8 / CH 1-24 INS – CH 73-96 INS / ST IN INS/UNIT LIB
[Function]
Make settings for the head amp assigned to the input channel/insert in point.
■ Console
In the LCD FUNCTION ACCESS
block, press the INPUT [HA/
INSERT] switch (press repeatedly
until the screen shown at the right
appears)
■ Display
MENU button → INPUT HA/
INSERT button → The tab corre-
sponding to the desired input chan-
nel/insert in point
When the CH 1-24 tab is selected
When the ST IN INS tab is selected
