Yamaha CS1D - Cards Specifications; Lmy2-Ml

Cards Specifications
79
Cards Specifications
• LMY2-ML
1. GENERAL SPECIFICATIONS
Output impedance of signal generator: 150Ω, fs=44.1k or 48kHz.
Frequency Response 20Hz-20kHz, refer to the nominal output level @1kHz
Gain Error @1kHz
Total Harmonic Distortion
Dynamic Range
* Dynamic range are measured with a 6dB/octave filter @12.7kHz; equivalent to a 20kHz filter with infinite dB/octave attenuation.
Hum & Noise @20Hz-20kHz
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz; equivalent to a 20kHz filter with infinite dB/octave attenuation.
Crosstalk @1kHz
INPUT OUTPUT
CONDITIONS
MIN TYP MAX UNITS
CH1A, 1B
CH2A, 2B
LMY4-DA
Gain: –68dB@+10dB –3 1 dB
Gain: +10dB@+10dB –2 1 dB
INPUT OUTPUT
CONDITIONS
MIN TYP MAX UNITS
CH1A, 1B
CH2A, 2B
LMY4-DA
Gain: –68dB@+10dB –1 1 dB
Gain: +10dB@+10dB –1 1 dB
INPUT OUTPUT
CONDITIONS
MIN TYP MAX UNITS
CH1A, 1B
CH2A, 2B
LMY4-DA
+10dB@20Hz–20kHz, Gain: –68dB 0.3 %
full scale output @1kHz, Gain: –68dB 0.05 %
+10dB@20Hz–20kHz, Gain: +10dB 0.02 %
full scale output @1kHz, Gain: +10dB 0.007 %
INPUT OUTPUT
CONDITIONS
MIN TYP MAX UNITS
CH1A, 1B
CH2A, 2B
LMY4-DA Gain: +10dB * 120 dB
INPUT OUTPUT
CONDITIONS
MIN TYP MAX UNITS
CH1A, 1B
CH2A, 2B
LMY4-DA
Equivalent Input Noise
Rs=150Ω, Gain: –68dB
–128 dB
CH1A, 1B
CH2A, 2B
LMY4-DA Rs=150Ω, Gain: –26dB –74 dB
INPUT TO/FROM
CONDITIONS
MIN TYP MAX UNITS
CH N CH (N-1) or (N+1) adjacent input –90 dB
CH N A CH N B adjacent input –90 dB
