Appendices
Preset EQ Program Parameters
• INPUT EQ LIBRARY
This is the EQ library that can be used on inputs. (All are read-only.)
#Title
Parameter
Description
LOW LOW MID HIGH MID HIGH
01 Bass Drum 1
PEAKING PEAKING PEAKING H.SHELF
Emphasizes the low range
of a bass drum and the
attack created by the
beater.
G
+3.5 dB –3.5 dB ±0.0 dB +4.0 dB
F
100 Hz 265 Hz 1.06 kHz 5.30 kHz
Q
1.2 10.0 0.90 —
02 Bass Drum 2
PEAKING PEAKING PEAKING LPF
Creates a peak around
80Hz, producing a tight,
stiff sound.
G
+8.0 dB –7.0 dB +6.0 dB —
F
80 Hz 400 Hz 2.50 kHz 12.5 kHz
Q
1.4 4.5 2.2
SLOPE: 12 dB
03 Snare Drum 1
PEAKING PEAKING PEAKING H.SHELF
Emphasizes snapping and
rimshot sounds.
G
–0.5 dB ±0.0 dB +3.0 dB +4.5 dB
F
132 Hz 1.00 kHz 3.15 kHz 5.00 kHz
Q
1.2 4.5 0.11 —
04 Snare Drum 2
L.SHELF PEAKING PEAKING PEAKING
Emphasizes the ranges of
that classic rock snare
drum sound.
G
+1.5 dB –8.5 dB +2.5 dB +4.0 dB
F
180 Hz 335 Hz 2.36 kHz 4.00 kHz
Q
— 10.0 0.70 0.10
05 Tom-tom 1
PEAKING PEAKING PEAKING PEAKING
Emphasizes the attack of
tom-toms, and creates a
long, “leathery” decay.
G
+2.0 dB –7.5 dB +2.0 dB +1.0 dB
F
212 Hz 670 Hz 4.50 kHz 6.30 kHz
Q
1.4 10.0 1.2 0.28
06 Cymbal
L.SHELF PEAKING PEAKING H.SHELF
Emphasizes the attack of
crash cymbals, extending
the “sparkling” decay.
G
–2.0 dB ±0.0 dB ±0.0 dB +3.0 dB
F
106 Hz 425 Hz 1.06 kHz 13.2 kHz
Q
— 8.0 0.90 —
07 High Hat
L.SHELF PEAKING PEAKING H.SHELF
A hi-hat setting that
slightly emphasizes the
mid to high range and
reduces the low range to
make the sound crisp.
You can use LOW MID G
(gain) to adjust the boost/
cut of the attack portion.
G
–4.0 dB –2.5 dB +1.0 dB +0.5 dB
F
95 Hz 425 Hz 2.80 kHz 7.50 kHz
Q
— 0.50 1.0 —
08 Percussion
L.SHELF PEAKING PEAKING H.SHELF
Emphasizes the attack and
clarifies the high-range of
instruments, such as shak-
ers, cabasas, and congas.
G
–4.5 dB ±0.0 dB +2.0 dB ±0.0 dB
F
100 Hz 400 Hz 2.80 kHz 17.0 kHz
Q
— 4.5 0.56 —
09 E.Bass 1
L.SHELF PEAKING PEAKING H.SHELF
Makes a tight electric bass
sound by cutting very low
frequencies.
G
–7.5 dB +4.5 dB +2.5 dB ±0.0 dB
F
35.5 Hz 112 Hz 2.00 kHz 4.00 kHz
Q
— 5.0 4.5 —
