Yamaha CS1D - Output Comp Library

Appendices
10
• OUTPUT COMP LIBRARY
No. Title [Type] Compressor effect and parameter values
01 Comp [COMP] Compressor template preset for use on the overall mix.
02 Expand [EXPANDER] Expander template preset.
03 Compander(H) [COMPANDER H] Compander template preset.
04 Compander(S) [COMPANDER S]
05 Click Erase [EXPANDER] Use this as a gate if the click tone that the musicians listen to is loud
and you wish to eliminate it.
No.
THRESHOLD
(dB)
RATIO
( :1)
RANGE
(dB)
ATTAC K
(s)
OUT GAIN
(dB)
KNEE
WIDTH
(dB)
RELEASE
(s)
HOLD
(s)
DECAY
(s)
01 –8 2.5 — 60m 0.0 SOFT 2 — 250m — —
No.
THRESHOLD
(dB)
RATIO
( :1)
RANGE
(dB)
ATTAC K
(s)
OUT GAIN
(dB)
KNEE
WIDTH
(dB)
RELEASE
(s)
HOLD
(s)
DECAY
(s)
02 –23 1.7 — 1m 3.5 SOFT 2 — 70m — —
No.
THRESHOLD
(dB)
RATIO
( :1)
RANGE
(dB)
ATTAC K
(s)
OUT GAIN
(dB)
KNEE
WIDTH
(dB)
RELEASE
(s)
HOLD
(s)
DECAY
(s)
03 –10 3.5 — 1m 0.0 — 6 250m — —
04 –8 4 — 25m 0.0 — 24 180m — —
No.
THRESHOLD
(dB)
RATIO
( :1)
RANGE
(dB)
ATTAC K
(s)
OUT GAIN
(dB)
KNEE
WIDTH
(dB)
RELEASE
(s)
HOLD
(s)
DECAY
(s)
05 –33 2 — 1m 2.0 SOFT 2 — 284m — —
06 Limiter1 [COMPANDER S]
07 Limiter2 [COMP]
Limiter templates. 1 has a slow release, and 2 is a Peak Stop type.
No.
THRESHOLD
(dB)
RATIO
( :1)
RANGE
(dB)
ATTAC K
(s)
OUT GAIN
(dB)
KNEE
WIDTH
(dB)
RELEASE
(s)
HOLD
(s)
DECAY
(s)
06 –9 3 — 20m –3.0 — 90 3.90m — —
07 0 ∞ —0m0.0 HARD — 319m — —
08 Total Comp1 [COMP]
09 Total Comp2 [COMP]
These presets make the overall level consistent and improve the defini-
tion of the overall sound, and are effective when applied to the stereo
out during mixdown. Interesting effects can also be obtained with var-
ious adjustments when these are used on stereo sources.
No.
THRESHOLD
(dB)
RATIO
( :1)
RANGE
(dB)
ATTAC K
(s)
OUT GAIN
(dB)
KNEE
WIDTH
(dB)
RELEASE
(s)
HOLD
(s)
DECAY
(s)
08 –18 3.5 — 94m 2.5 HARD — 447m — —
09 –16 6 — 11m 6.0 SOFT 1 — 180m — —
