Yamaha CS1D - ST out DIGITAL (Stereo out Digital)

Global functions
68
ST OUT DIGITAL (stereo out digital)
[Function]
For the two STEREO OUT DIGIGAL jacks (A/B) of the CS1D, turn dithering on/off and specify the number
of quantization bits for the output signal.
■ Console
In the LCD FUNCTION ACCESS
block, press the [MON/CUE] switch
(press repeatedly until the screen
shown at the right appears)
■ Display
MENU button → MON/CUE but-
ton → ST OUT DIGITAL tab
[Screen functions]
1 DITHER ON/OFF
Switch dithering on/off for STEREO OUT DIGITAL
jacks A/B.
2 Number of bits
Select the number of quantization bits for STEREO
OUT DIGITAL jacks A/B.
You can select from 24 bits – 16 bits.
1
2
