General Specifications
53
General Specifications
TALKBACK IN
Output impedance of signal generator: 150Ω, MONITOR OUT ANALOG volume MAX, fs= 44.1k or 48kHz
Frequency Response 20Hz-20kHz, refer to the nominal output level @1kHz
Gain Error @1kHz
Total Harmonic Distortion
*Total Harmonic Distortion are measured with a 6dB/octave filter @80kHz.
Dynamic Range
* Dynamic range are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation.
Hum & Noise @20Hz-20kHz
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation
2-TRACK IN
Output impedance of signal generator: 150Ω, MONITOR OUT ANALOG volume MAX, fs= 44.1k or 48kHz
Frequency Response 20Hz-20kHz, refer to the nominal output level @1kHz
Gain Error @1kHz
Total Harmonic Distortion
*Total Harmonic Distortion are measured with a 6dB/octave filter @80kHz.
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
TALKBACK IN 1, 2
MONITOR OUT
ANALOG
Gain: –44dB@+10dB –2 1 dB
Gain: +10dB@+10dB –2 1 dB
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
TALKBACK IN 1, 2
MONITOR OUT
ANALOG
Gain: –44dB@+10dB –1 1 dB
Gain: +10dB@+10dB –1 1 dB
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
TALKBACK IN 1, 2
MONITOR OUT
ANALOG
+10dB@20Hz-20kHz, Gain: –44dB 0.1 %
full scale output @1kHz, Gain: –44dB 0.02 %
+10dB@20Hz-20kHz, Gain: +10dB 0.02 %
full scale output @1kHz, Gain: +10dB 0.02 %
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
TALKBACK IN 1, 2
MONITOR OUT
ANALOG
Gain: +10dB
*
105 dB
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
TALKBACK IN 1, 2
MONITOR OUT
ANALOG
Equivalent Input Noise
Rs= 150Ω, Gain: –44dB
–127 dB
Rs= 150Ω, Gain: +10dB –81 dB
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
2-TRACK IN 1, 2
ANALOG
MONITOR OUT
ANALOG
@+10dB –2 1 dB
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
2-TRACK IN 1, 2
ANALOG
MONITOR OUT
ANALOG
@+10dB –1 1 dB
INPUT OUTPUT CONDITIONS MIN TYP MAX
UNITS
2-TRACK IN 1, 2
ANALOG
MONITOR OUT
ANALOG
+10dB@20Hz-20kHz 0.02 %
full scale output @1kHz 0.01 %
