Appendices
54
Dynamic Range
* Dynamic range are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation.
Crosstalk @1kHz
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation
MONITOR OUT ANALOG & CUE OUT ANALOG
Output impedance of signal generator: 150Ω, fs= 44.1k or 48kHz
Frequency Response 20Hz-20kHz, refer to the nominal output level @1kHz
Gain Error @1kHz
Total Harmonic Distortion
*Total Harmonic Distortion are measured with a 6dB/octave filter @80kHz.
Hum & Noise residual output noise
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation.
Dynamic Range
* Dynamic range are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation.
INPUT OUTPUT CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1, 2
ANALOG
MONITOR OUT
ANALOG
* 110 dB
FROM/TO TO/FROM CONDITIONS MIN TYP MAX UNITS
2-TRACK IN N L
ANALOG
2-TRACK IN N R
ANALOG
adjacent inputs –80 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX
UNITS
2-TRACK IN 1
ANALOG
MONITOR OUT
ANALOG
600Ω volume MAX @+10dB –2 1 dB
CUE OUT
ANALOG
600Ω volume MAX @+10dB –2 1 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1
ANALOG
MONITOR OUT
ANALOG
600Ω volume MAX @+10dB –1 1 dB
CUE OUT
ANALOG
600Ω volume MAX @+10dB –1 1 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1
ANALOG
MONITOR OUT
ANALOG
600Ω
+10dB@20Hz-20kHz, volume MAX 0.02 %
full scale output @1kHz, volume MAX 0.01 %
CUE OUT
ANALOG
600Ω
+10dB@20Hz-20kHz, volume MAX 0.02 %
full scale output @1kHz, volume MAX 0.01 %
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1
ANALOG
MONITOR OUT
ANALOG
600Ω
* volume MAX –86 dB
* volume MIN –100 dB
CUE OUT
ANALOG
600Ω
* volume MAX –86 dB
* volume MIN –100 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1
ANALOG
MONITOR OUT
ANALOG
600Ω volume MAX @+10dB 110 dB
CUE OUT
ANALOG
600Ω volume MAX @+10dB 110 dB
