General Specifications
55
Crosstalk @1kHz
PHONES OUT
Output impedance of signal generator: 150Ω, fs= 44.1k or 48kHz
Frequency Response 20Hz-20kHz, refer to the nominal output level @1kHz
Gain Error @1kHz
Total Harmonic Distortion
Hum & Noise
* Hum & Noise are measured with a 6dB/octave filter @12.7kHz;
equivalent to a 20kHz filter with infinite dB/octave attenuation.
Crosstalk @1kHz
ANALOG INPUT (AI8 plus LMY2-ML)
ANALOG INPUT (AI8 plus LMY4-AD)
DIGITAL INPUT (DIO8)
FROM/TO TO/FROM CONDITIONS MIN TYP MAX UNITS
MONITOR OUT A, B L
ANALOG
MONITOR OUT A, B
R ANALOG
adjacent inputs –80 dB
CUE OUT L
ANALOG
CUE OUT R
ANALOG
adjacent inputs –80 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX
UNITS
2-TRACK IN 1
ANALOG
PHONES
A1, B1, A2, B2
8Ω volume MAX @0dB –3 1 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1
ANALOG
PHONES
A1, B1, A2, B2
8Ω volume MAX @0dB –2 2 dB
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
2-TRACK IN 1
ANALOG
PHONES
A1, B1, A2, B2
8Ω +10dB@20Hz-20kHz, volume MAX 0.7 %
8Ω full scale output @1kHz, volume MAX 1%
INPUT OUTPUT RL CONDITIONS MIN TYP MAX UNITS
—
PHONES
A1, B1, A2, B2
8Ω * volume MAX –88 dB
8Ω * volume MIN –92 dB
FROM/TO TO/FROM RL CONDITIONS MIN TYP MAX UNITS
PHONES
A1, B1, A2, B2 L
PHONES
A1, B1, A2, B2 R
8Ω adjacent inputs –55 dB
40Ω adjacent inputs –60 dB
A/B select
phantom ON/OFF
analog gain control
AD converter
digital gain control
+48V DC is individually supplied inputs.
–68 - +10dB (6dB step)
24bit linear +4bit floating, 128 times oversampling.
0 - 6dB (1dB step)
AD converter 24bit linear +4bit floating, 128 times oversampling
Option card MY8, MY4 series
