Appendices
56
INPUT CHANNEL CH 1-48(DSP1D) / CH 1-96(DSP1D-EX)
Phase normal / reverse
Input patch
De-emphasis automatic de-emphasis filter (15µs/50µs)
Attenuator –96 - 0dB (1dB step)
High pass filter 20Hz – 600Hz (60 point)
slope –6dB / –12dB / –18dB
on/off
Equalizer
4 band PEQ
on/off
crossover gain –3dB / –4dB / –5dB / –6dB
LOW LOW-MID HIGH-MID HIGH / LPF
Q 0.1 - 10 0.1 - 10 0.1 - 10 0.1 - 10
(41 point) (41 point) (41 point) (41 point)
low shelving high shelving
LPF
F 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz
(1/12 oct step) (1/12 oct step) (1/12 oct step) (1/12 oct step)
G –18dB - +18dB –18dB - +18dB –18dB - +18dB –18dB - +18dB
(0.5dB step) (0.5dB step) (0.5dB step) (0.5dB step)
Gate on/off
key in self pre EQ / self post EQ / left CH/key in source1
/ key in source2 / key in source3 / key in source4
key in LPF on/off 20Hz - 20kHz (1/12 oct step)
key in HPF on/off 20Hz - 20kHz (1/12 oct step)
key in cue on/off
key in link on/off
gate
ducking
Compressor on/off
key in self pre EQ / self post EQ / left CH / key in source1
/ key in source2 / key in source3 / key in source4
input filter LPF / HPF on/off 20Hz - 20kHz (1/12 oct step)
key in link on/off
comp
expander
compander hard
compander soft
Delay 0 - 250msec (0.02msec step)
Fader 100mm motorized –∞, –90 - +10dB (128 step/100mm)
input / mix 1-48
DCA DCA assign 1-12
ON/OFF
Cue on/off
Mute mute group 1-12
Pan 127 positions (L= 1 - 63, center, R= 1 - 63)
pan mode individual / gang pan / inv.gang
Routing stereo on/off
mix 1 - 48 on/off, pre/post, fix / vari
vari: level
Direct out pre EQ / pre fader / post fader / post on
Metering peak hold on/off
