Yamaha CS1D - Output Eq Library

Preset EQ Program Parameters
5
• OUTPUT EQ LIBRARY
This is the EQ library that can be used on outputs. (All are read-only.)
#Title
Parameter
Description
SUB
LOW
LOW
LOW
MID
MID
HIGH
MID
HIGH
01 Total EQ 1
PEAKING PEAKING PEAKING PEAKING PEAKING H.SHELF
Use on a stereo mix dur-
ing mixdown. Sounds
even better when used
with a compressor.
G
–0.5 dB ±0.0 dB ±0.0 dB ±0.0 dB +3.0 dB +6.5 dB
F
95 Hz 1.0 kHz 950 Hz 2.5 kHz 2.12 kHz 16.0 kHz
Q
7.0 1.0 2.2 1.0 5.6 —
02 Total EQ 2
PEAKING PEAKING PEAKING PEAKING PEAKING H.SHELF
A variation on program
01.
G
+4.0 dB ±0.0 dB +1.5 dB ±0.0 dB +2.0 dB +6.0 dB
F
95 Hz 1.0 kHz 750 Hz 2.5 kHz 1.80 kHz 18.0 kHz
Q
7.0 1.0 2.8 1.0 5.6 —
03 Total EQ 3
L.SHELF PEAKING PEAKING PEAKING PEAKING H.SHELF
A variation on program
01. 01–03 can also be
used with stereo inputs or
external effect returns.
G
+1.5 dB ±0.0 dB +0.5 dB ±0.0 dB +2.0 dB +4.0 dB
F
67 Hz 1.0 kHz 850 Hz 2.5 kHz 1.90 kHz 15.0 kHz
Q
— 1.0 0.28 1.0 0.70 —
