Yamaha CS1D - Page 549

Appendices
4
32 Tom-tom 2
L.SHELF PEAKING PEAKING H.SHELF
A variation on program
05. Emphasizes the mid
and high range.
G
–9.0 dB +1.5 dB +2.0 dB ±0.0 dB
F
90 Hz 212 Hz 5.30 kHz 17.0 kHz
Q
— 4.5 1.2 —
33 Piano 3
PEAKING PEAKING PEAKING H.SHELF
A variation on program
13, 14.
G
+4.5 dB –13.0 dB +4.5 dB +2.5 dB
F
100 Hz 475 Hz 2.36 kHz 10.0 kHz
Q
8.0 10.0 9.0 —
34 Piano Low
PEAKING PEAKING PEAKING H.SHELF
Use for the low range of a
piano sound recorded in
stereo.
G
–5.5 dB +1.5 dB +6.0 dB ±0.0 dB
F
190 Hz 400 Hz 6.70 kHz 12.5 kHz
Q
10.0 6.3 2.2 —
35 Piano High
PEAKING PEAKING PEAKING PEAKING
Use for the high range of a
piano sound recorded in
stereo.
G
–5.5 dB +1.5 dB +5.0 dB +3.0 dB
F
190 Hz 400 Hz 6.70 kHz 5.60 kHz
Q
10.0 6.3 2.2 0.10
36 Fine-EQ Cass
L.SHELF PEAKING PEAKING H.SHELF
Use when recording to or
from cassette tape to
make the sound clearer.
G
–1.5 dB ±0.0 dB +1.0 dB +3.0 dB
F
75 Hz 1.00 kHz 4.00 kHz 12.5 kHz
Q
— 4.5 1.8 —
37 Narrator
PEAKING PEAKING PEAKING H.SHELF
Use when recording narra-
tion.
G
–4.0 dB –1.0 dB +2.0 dB ±0.0 dB
F
106 Hz 710 Hz 2.50 kHz 10.0 kHz
Q
4.0 7.0 0.63 —
#Title
Parameter
Description
LOW LOW MID HIGH MID HIGH
