Yamaha CS1D - Phaser; Auto Pan

Effects Parameters
25
• PHASER [Type: STEREO]
*1
• FREQ. is calculated from the [TEMPO] and [NOTE].
• AUTO PAN [Type: STEREO]
*1
• FREQ. is calculated from the [TEMPO] and [NOTE].
Parameter Range Description
TEMPO 20 - 300
Tempo (BPM) value that is the basis for calculating the
modulation speed
FREQ. 0.05 - 40.00 [Hz] Modulation speed
NOTE *1
Used in conjunction with TEMPO to determine modulation
speed
DEPTH 0 - 100 [%] Modulation depth
FB.LEVEL –99 - +99 [%] Feedback gain
HI.RATIO 0.1 - 1.0 High-frequency feedback ratio
OFFSET 0 - 100 Lowest phase-shifted frequency offset
STAGE 2, 4, 6, 8, 10, 12, 14, 16 Number of phase shift stages
LOW SHEL. F Thru, 21 - 8.0k [Hz] Low-range shelving filter frequency
LOW SHEL. G –12.0 - +12.0 [dB] Low-range shelving filter gain
PEQ F 100 - 8.0k [Hz] Parametric EQ cutoff frequency
PEQ G –12.0 - +12.0 [dB] Parametric EQ gain
PEQ Q 10.0 - 0.1 Parametric EQ Q
HIGH SHEL. F 50 - 16.0k, Thru [Hz] High-range shelving filter frequency
HIGH SHEL. G –12.0 - +12.0 [dB] High-range shelving filter gain
BALANCE WAT 0 - 100 [%] Wet/dry balance
Parameter Range Description
TEMPO 20 - 300
Tempo (BPM) value that is the basis for calculating the
modulation speed
FREQ. 0.05 - 40.00 [Hz] Modulation speed
NOTE *1
Used in conjunction with TEMPO to determine modulation
speed
DEPTH 0 - 100 [%] Modulation depth
DIRECTION L<->R, L->R, L<-R, Turn L, Turn R Panning direction
WAVE Sine, Tri, Square Modulation waveform
LOW SHEL. F Thru, 21 - 8.0k [Hz] Low-range shelving filter frequency
LOW SHEL. G –12.0 - +12.0 [dB] Low-range shelving filter gain
PEQ F 100 - 8.0k [Hz] Parametric EQ cutoff frequency
PEQ G –12.0 - +12.0 [dB] Parametric EQ gain
PEQ Q 10.0 - 0.1 Parametric EQ Q
HIGH SHEL. F 50 - 16.0k, Thru [Hz] High-range shelving filter frequency
HIGH SHEL. G –12.0 - +12.0 [dB] High-range shelving filter gain
BALANCE WAT 0 - 100 [%] Wet/dry balance
