Yamaha CS1D - MATRIX OUTPUT Block

CS1D Reference Manual (Hardware)
46
MATRIX OUTPUT block
[Function]
In this block you can set the level and on/off status of the signals that are sent from MIX channels 1–48, STE-
REO A, B channel, and SUB IN channels to MATRIX buses 1–24, and send them to the output unit that is
patched to each MATRIX channel.
PAI RPAI R
PAI RPAIR
PAI R
MATRIX
LAYER
ON ON ON ON ON ON ON ON ON ON ON ON
1 - 12
PAI R
MATRIX OUTPUT
block
