•GATE REVERB, REVERSE GATE [Type: STEREO]
• DELAY LCR [Type: MIX]
*1
• Delay Time is calculated from the [TEMPO] and [NOTE].
Parameter Range Description
ER. TYPE Type-A, Type-B Type of early reflection (ER.) simulation
ROOM SIZE 0.1 - 20.0 Reflection spacing
LIVENESS 0 - 10 Early reflections decay characteristics (0= dead, 10= live)
INI.DELAY 0.0 - 500.0 [ms] Initial delay before reverb begins
DIFFUSION 0 - 10 Reverb diffusion (left-right reverb spread)
DENSITY 0 - 100 [%] Reverb density
ER. NUM. 1 - 34 Number of early reflections
FB.DELAY 0.0 - 1000.0 [ms] Feedback delay time
FB.LEVEL –99 - +99 [%] Feedback gain
HI.RATIO 0.1 - 1.0 High-frequency feedback ratio
HPF Thru, 21 - 8.0k [Hz] High-pass filter cutoff frequency
LPF 50 - 16.0k, Thru [Hz] Low-pass filter cutoff frequency
SPACE MOD 0 - 10 Modulation depth
BALANCE WAT 0 - 100 [%] Wet/dry balance
Parameter Range Description
TEMPO 20 - 300
Tempo (BPM) value that is the basis for calculating the
delay time
DELAY L 0.0 - 5460.0 [ms] Left channel delay time
NOTE L *1 Used in conjunction with TEMPO to determine delay time
LEVEL L –100 - +100 [%] Left channel level
DELAY C 0.0 - 5460.0 [ms] Center channel delay time
NOTE C *1 Used in conjunction with TEMPO to determine delay time
LEVEL C –100 - +100 [%] Center channel level
DELAY R 0.0 - 5460.0 [ms] Right channel delay time
NOTE R *1 Used in conjunction with TEMPO to determine delay time
LEVEL R –100 - +100 [%] Right channel level
FB.DELAY 0.0 - 5460.0 [ms] Feedback delay time
NOTE FB. *1 Used in conjunction with TEMPO to determine delay time
FB.LEVEL –99 - +99 [%] Feedback gain
HI.RATIO 0.1 - 1.0 High-frequency feedback ratio
HPF Thru, 21 - 8.0k [Hz] High-pass filter cutoff frequency
LPF 50 - 16.0k, Thru [Hz] Low-pass filter cutoff frequency
BALANCE WAT 0 - 100 [%] Wet/dry balance
