[Procedure]
1. Press a [SEL] switch in the MIX OUTPUT block,
MATRIX OUTPUT block, or STEREO OUTPUT
block to select the output channel that you wish to
control.
2. In the EQUALIZER section of the SELECTED OUT-
PUT CHANNEL block, turn on the [EQ ON]
switch.
The 6 band EQ of the corresponding channel will be
enabled.
3. For each band, use the [Q] encoder, [FREQUENCY]
encoder, and [GAIN] encoder to set the steepness,
center frequency, and gain respectively.
4. If you wish to use the HIGH band or SUB LOW
band as a shelving type EQ, turn on the [ ] switch
of the corresponding band.
5. If you wish to use the HIGH band as an LPF, turn
on the [LPF] switch of the HIGH band.
6. If you wish to use the SUB LOW band as an HPF,
turn on the [HPF] switch of the SUB LOW band.
Hint
You can make settings so that the corresponding
screen appears automatically when you operate the
EQUALIZER section. This setting is made in the
UTILITY function PREFERENCE screen.
In the same way as for the compressor or noise gate,
EQ settings can be stored to or recalled from a dedi-
cated EQ library. However, the output channel EQ
library is independent of the input channel EQ
library, and settings cannot be loaded/saved between
these libraries.
