CS1D Operating Manual (Basic Operation)
114
Hint
In the MONITOR B screen you can also use DIRECT
IN to directly monitor the signal from a specific
input jack. For details refer to “CS1D Reference Man-
ual (Software)”.
4. In the MASTER block MONITOR B section, press
one of the SOURCE [2TR IN 1]/[2TR IN 2]/[ST A]/
[ST B]/[MONITOR B]/[DEFINE] switches to select
the source that you wish to monitor.
The following sources correspond to each switch.
• [2TR IN 1] switch ....The input signal from the 2-
TRACK IN DIGITAL 1 jack
or 2-TRACK IN ANALOG 1
jacks located on the CS1D
rear panel
• [2TR IN 2] switch ....The input signal from the 2-
TRACK IN DIGITAL 2 jack
or 2-TRACK IN ANALOG 2
jacks located on the CS1D
rear panel
• [ST A] switch............The output signal of the STE-
REO A channel
• [ST B] switch............The output signal of the STE-
REO B channel
• [MONITOR A] switch
The same signal as the moni-
tor source currently selected
in the MONITOR A section
• [DEFINE] switch .....The signal previously speci-
fied in the display (MON/
CUE function MONITOR B
screen)
5. Turn on the MONITOR B [ON] switch.
6. Use the MONITOR B [LEVEL] volume to adjust the
output level from the MONITOR OUT B jacks.
Alternatively, use the MONITOR B [PHONES] vol-
ume to adjust the output level of the PHONES
MONITOR B jack.
