CS1D Reference Manual (Hardware)
2
CS1D front panel
•
For details on the specifications and functions of the
engine (DSP unit) and input/output units, refer to
the owner’s manual for each device.
•
For details on installation and connection of the
PM1D system, refer to “CS1D Operating Manual
(Start-up).”
•
For details on basic operation of the PM1D system,
refer to “CS1D Operating Manual (Basic Opera-
tion).”
•
For details on the functions and operations within
the display of the CS1D, refer to “CS1D Reference
Manual (Software).”
Screen shots shown in this manual are taken from a
prototype. Please be aware that they may differ
slightly from the actual screens on your unit.
MOUSE KEYBOARD MONITOR A MONITOR B
12
43
56
12
43
56
Front panel block (→p.114)
To Next Page
