MATRIX/ST (matrix/stereo) function
109
OUT PATCHOUT INSERTOUT EQOUT COMPOUT DELAY
OUT DCA/MUTE
MATRIX/STOUT CH VIEW
• When the POST ON button is on
The signal will be sent from immediately after the
MIX [ON] switch or STEREO A/B [ON] switch of
the CS1D.
6 Pairing
This displays the number and short name of the send
source MIX channel/STEREO A/B channel and pair-
ing status.
You can click the heart symbol to set/defeat pairing.
Hint
If the send source MIX channels are paired, the fad-
ers and buttons will be shared as shown in the fol-
lowing diagram.
To Next Page
