IN GATE/COMP function
141
IN PATCHIN HA/INSERTIN EQ
IN GATE/COMP
IN DELAYIN DCA/MUTE
PAN/ROUTING
IN CH VIEW
E SELECT
Select the key-in signal from the following choices.
• SELF PRE EQ
Pre-EQ signal of the currently selected input channel
• SELF POST EQ
Post-EQ signal of the currently selected input chan-
nel
• LEFT CH
Post-EQ signal of the previous-numbered input
channel
• KEY IN 1–KEY IN 4
Signal of the input channel selected in the respective
CH SELECT menu
If input channel 1 or the L channel of a ST IN chan-
nel is selected, the LEFT CH button will not be dis-
played.
F LPF ON/OFF (low pass filter on/off)
This button is an on/off switch for the low pass filter
of the key-in signal.
G Knob
This knob sets the cutoff frequency of the low pass
filter. The numerical box below shows the current
value.
If input channel 1 or the L channel of a ST IN chan-
nel is selected, the LEFT CH button will not be dis-
played.
H HPF ON/OFF (high pass filter on/off)
This button is an on/off switch for the high pass filter
of the key-in signal.
I Knob
This knob sets the cutoff frequency of the low pass
filter. The numerical box below shows the current
value.
Hint
The low pass filter and high pass filter do not affect
the signal that is sent from the original input channel
to the various buses.
