Appendices
58
MIX 1-48 (DSP1D, DSP1D-EX)
MATRIX 1-24 (DSP1D, DSP1D-EX)
STEREO OUT A, B (DSP1D, DSP1D-EX)
Equalizer 6 band PEQ (SUB LOW, LOW, LOW MID, MID, HIGH MID, HIGH)
bypass on/off
SUB LOW / LOW SHELVING / HPF
HIGH / HIGH SHELVING / LPF
parameter are as same as input CH Equalizer
Compressor parameter are as same as input CH Compressor.
Delay 0 - 1000msec (0.02msec step)
Level control rotary encoder
DCA DCA assign 9-12
ON/OFF
MIX to STEREO on/off
pre fader / post fader
MIX to STEREO Pan 127 positions (L= 1 - 63, center, R= 1 - 63)
Cue on/off
Mute mute group 1-12
Metering peak hold on/off
Output patch
Dither on/off
word length 16bit - 24bit (DIO8 only)
Send level mix 1-48, stereo A, B
Send on/off mix 1-48, stereo A, B
Equalizer parameter are as same as input MIX Equalizer
Compressor parameter are as same as input MIX Compressor.
Delay 0 - 1000msec (0.02msec step)
Level control rotary encoder
DCA DCA assign 9-12
ON/OFF
Cue on/off
Metering peak hold on/off
Output patch
Dither on/off
word length 16bit - 24bit (DIO8 only)
Equalizer parameter are as same as input MIX Equalizer
Compressor parameter are as same as input MIX Compressor.
Delay 0 - 1000msec (0.02msec step)
Fader 100mm motorized –∞, –90 - +10dB (128 step/100mm)
Balance 127 positions (L= 1 - 63, center, R= 1 - 63)
ON/OFF
Cue on/off
Metering peak hold on/off
Output patch
Dither on/off
word length 16bit - 24bit (DIO8 only)
