Controls & Indicators
61
ST IN BLOCK
MIX OUT BLOCK
MATRIX OUT BLOCK
STEREO OUT BLOCK
Keys (w/ LED) ST IN 1-4/5-8 ON, ST IN 1-4/5-8 L SEL, ST IN 1-4/5-8 R SEL
ST IN 1-4/5-8 TO ST, ST IN 1-4/5-8 CUE
Keys ST IN 1-4/5-8 ASSIGN DCA
Faders ST IN 1-4/5-8
Rotary encoders (w/ 25 points LEDs) ST IN 1-4/5-8 GAIN, ST IN 1-4/5-8 PAN, ST IN 1-4/5-8 MIX
4 digits 5 x 7 dot LED ST IN 1-4/5-8 NAME
LEDs ST IN 1-4/5-8 SAFE SELECT
ST IN 1-4/5-8 DCA SELECT
ST IN 1-4/5-8 INPUT meter 6 elements x 2
ST IN 1-4/5-8 GATE meter 3 elements x 2
ST IN 1-4/5-8 COMP meter 3 elements x 2
ST IN 1-4/5-8 CLIP L, R
ST IN 1-4/5-8 A SELECT
ST IN 1-4/5-8 B SELECT
ST IN 1-4/5-8 PHANTOM +48V
ST IN 1-4/5-8 INSERT
ST IN 1-4/5-8 PHASE
ST IN 1-4/5-8 MIX ON
ST IN 1-4/5-8 STATUS L, R
Keys (w/ LED) MIX 1-24/25-48 ON, MIX 1-24/25-48 SEL,
MIX 1-24/25-48 TO ST, MIX 1-24/25-48 CUE
MIX 1-24/25-48 TO MATRIX
MIX LAYER 1-24 SELECT, MIX LAYER 25-48 SELECT
Keys MIX 1-24/25-48 ASSIGN DCA
Rotary encoders (w/ 25 points LEDs) MIX 1-24/25-48 LEVEL
4 digits 5 x 7 dot LED MIX 1-24/25-48 NAME
LEDs MIX 1-24/25-48 SAFE SELECT
MIX 1-24/25-48 DCA SELECT
MIX 1-24/25-48 INSERT
Keys (w/ LED) MATRIX 1-12/13-24 ON, MATRIX 1-12/13-24 SEL,
MATRIX 1-12/13-24 CUE
MATRIX LAYER 1-12 SELECT
MATRIX LAYER 13-24 SELECT
Rotary encoders (w/ 25 points LEDs) MATRIX 1-12/13-24 LEVEL
4 digits 5 x 7 dot LED MATRIX 1-12/13-24 NAME
LEDs MATRIX 1-12/13-24 SAFE SELECT
MATRIX 1-12/13-24 INSERT
Keys (w/ LED) STEREO A ON, STEREO B ON
STEREO A SEL, STEREO B SEL
STEREO A CUE, STEREO B CUE
STEREO A TO MTRX, STEREO B MONO
Fader STEREO A, STEREO B
LEDs STEREO A SAFE SELECT, STEREO B SAFE SELECT
STEREO A INSERT, STEREO B INSERT
