1.2 Model Number and Nameplate Check
24 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
No.
E1-01 [Input AC Supply Voltage] < 460
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable
Motor Output
kW
Rated Output Current
A
Maximum Applicable
Motor Output
kW
Rated Output Current
A
168 75 150 90 168
208 90 180 110 208
250 110 216 132 250
296 132 260 160 296
371 160 304 200 371
389 200 371 220 389
453 220 414 250 453
568 250 453 315 568
675 315 605 355 675
Table 1.4 Three-Phase AC 400 V Class (Input Voltage ≥ 460 V)
No.
E1-01 [Input AC Supply Voltage] ≥ 460
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable
Motor Output
HP
Rated Output Current
A
Maximum Applicable
Motor Output
HP
Rated Output Current
A
002 3/4 1.6 1 2.1
004 1 2.1 2 3
005 2 3.4 3 4.8
007 3 4.8 4 6.9
009 4 6.9 5 7.6
012 5 7.6 7 1/2 11
018 7 1/2 11 10 14
023 10 14 15 21
031 15 21 20 27
038 20 27 25 34
044 25 34 30 40
060 30 40 40 52
075 40 52 50 65
089 50 65 60 77
103 60 77 75 96
140 75 96 100 124
168 100 124 125 156
208 125 156 150 180
250 150 180 200 240
296 200 240 250 302
371 250 302 300 361
389 300 361 350 414
453 350 414 400 477
