Receiving
1
1.2 Model Number and Nameplate Check
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 23
No.
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable
Motor Output
kW
Rated Output Current
A
Maximum Applicable
Motor Output
kW
Rated Output Current
A
010 1.5 8 2.2 9.6
012 2.2 11 3 12.2
018 3 14 4 17.5
021 4 17.5 5.5 21
030 5.5 25 7.5 30
042 7.5 33 11 42
056 11 47 15 56
070 15 60 18.5 70
082 18.5 75 22 82
110 22 88 30 110
138 30 115 37 138
169 37 145 45 169
211 45 180 55 211
257 55 215 75 257
313 75 283 90 313
360 90 346 110 360
415 110 415 - -
Table 1.3 Three-Phase AC 400 V Class (Input Voltage < 460 V)
No.
E1-01 [Input AC Supply Voltage] < 460
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable
Motor Output
kW
Rated Output Current
A
Maximum Applicable
Motor Output
kW
Rated Output Current
A
002 0.55 1.8 0.75 2.1
004 1.1 3.4 1.5 4.1
005 1.5 4.8 2.2 5.4
007 2.2 5.5 3.0 7.1
009 3.0 7.2 4.0 8.9
012 4.0 9.2 5.5 11.9
018 5.5 14.8 7.5 17.5
023 7.5 18 11 23.4
031 11 24 15 31
038 15 31 18.5 38
044 18.5 39 22 44
060 22 45 30 59.6
075 30 60 37 74.9
089 37 75 45 89.2
103 45 91 55 103
140 55 112 75 140
