1.2 Model Number and Nameplate Check
22 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
Table 1.1 Model Number Details
No 詳細
1 Drive
2 Product series
3 Region code
• A: Japan
• B: China
• C: Europe
• D: India
• K: Korea
• T: Asia (Singapore and Taiwan)
• U: the Americas
4 Input power supply voltage
• 2: Three-Phase AC 200 V
• 4: Three-Phase AC 400 V
5 Rated output current
Note:
Refer to the rated output current list for more information.
6
EMC noise filter
• A: No internal EMC filter
• B: Internal category C3 EMC filter
• C: Internal category C2 EMC filter
7 Protection design
• B: IP20
• F: IP20, UL Type 1
8 Environmental specification (Reserved)
9 Design revision order
10 Control circuit terminal board (Reserved)
11 Option card (connector CN5-A) (Reserved)
12 Option card (connector CN5-B) (Reserved)
13 Option card (connector CN5-C) (Reserved)
14 Keypad (Reserved)
15 Special applications (Reserved)
■ Rated Output Current
Table 1.2 to Table 1.4 give the rated output current values.
Note:
• These output current values are applicable for drives that operate at standard specifications.
• Derate the current in applications that:
–Increase the carrier frequency
–Have high ambient temperature
–Install drives side-by-side.
• Use C6-01 [Normal / Heavy Duty Selection] to select Normal Duty rating (ND) or Heavy Duty rating (HD).
Table 1.2 Three-Phase AC 200 V Class
No.
Heavy Duty Rating (HD)
[C6-01 = 0]
(Default)
Normal Duty Rating (ND)
[C6-01 = 1]
Maximum Applicable
Motor Output
kW
Rated Output Current
A
Maximum Applicable
Motor Output
kW
Rated Output Current
A
004 0.55 3.2 0.75 3.5
006 0.75 5 1.1 6
