Standards Compliance
4
4.2 European Standards
YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual 255
Model EMC Noise Filter Model Quantity Manufacturer
4250A FS5972-250-37 1 Schaffner
4296A FS5972-410-99 1 Schaffner
4371A FS5972-410-99 1 Schaffner
4389A FS5972-410-99 1 Schaffner
4453A FS5972-600-99 1 Schaffner
4568A FS5972-600-99 1 Schaffner
4675A FS5972-410-99 2 Schaffner
■ DC Reactor
To comply with IEC/EN 61000-3-2, install a DC reactor to drive models 2004, 2006, 4002, and 4004 when using
an internal or external EMC filter. Refer to Table 4.11 to select the correct DC reactor.
Table 4.11 DC Reactors for Harmonic Suppression (Manufacturer: Yaskawa Electric)
Drive Model DC Reactor Model DC Reactor Rating
2004 UZDA-B 5.4 A, 8 mH
2006 UZDA-B 5.4 A, 8 mH
4002 UZDA-B 3.2 A, 28 mH
4004 UZDA-B 3.2 A, 28 mH
