10.9 F: Options
540 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-50
(03C1)
DeviceNet MAC
Address
Sets the MAC address for DeviceNet communication. Restart the
drive after you change this setting.
Note:
Be sure to set a MAC address that is different than all other node
addresses. Do not set this parameter to 0. Incorrect parameter
settings will cause AEr [Station Address Setting Error] errors
and the MS LED on the option will flash.
0
(0 - 64)
851
F6-51
(03C2)
DeviceNet Baud
Rate
Sets the DeviceNet communications speed. Restart the drive after
you change this setting.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
3 : Adjustable from Network
4 : Detect Automatically
0
(0 - 4)
851
F6-52
(03C3)
DeviceNet PCA
Setting
Sets the format of data that the DeviceNet communication master
sends to the drive.
21
(0 - 255)
851
F6-53
(03C4)
DeviceNet PPA
Setting
Sets the format of data that the drive sends to the DeviceNet
communication master.
71
(0 - 255)
851
F6-54
(03C5)
DeviceNet Idle
Fault Detection
Sets the function to detect EF0 [Option Card External Fault] when
the drive does not receive data from the DeviceNet master.
0 : Enabled
1 : Disabled, No Fault Detection
2 : Vendor Specific
3 : RUN Forward
4 : RUN Reverse
0
(0 - 4)
852
F6-55
(03C6)
DeviceNet Baud
Rate Monitor
Sets the function to see the actual DeviceNet communications speed
using the keypad. This parameter functions as a monitor only.
0 : 125 kbps
1 : 250 kbps
2 : 500 kbps
0
(0 - 2)
852
F6-56
(03D7)
DeviceNet Speed
Scaling
Sets the speed scale for DeviceNet communication.
0
(-15 - +15)
852
F6-57
(03D8)
DeviceNet Current
Scaling
Sets the current scale of the DeviceNet communication master.
0
(-15 - +15)
852
F6-58
(03D9)
DeviceNet Torque
Scaling
Sets the torque scale of the DeviceNet communication master.
0
(-15 - +15)
852
F6-59
(03DA)
DeviceNet Power
Scaling
Sets the power scale of the DeviceNet communication master.
0
(-15 - +15)
852
F6-60
(03DB)
DeviceNet Voltage
Scaling
Sets the voltage scale of the DeviceNet communication master.
0
(-15 - +15)
853
F6-61
(03DC)
DeviceNet Time
Scaling
Sets the time scale of the DeviceNet communication master.
0
(-15 - +15)
853
F6-62
(03DD)
DeviceNet
Heartbeat Interval
Sets the heartbeat for DeviceNet communication. Set this parameter
to 0 to disable the heartbeat function.
0
(0 - 10)
853
F6-63
(03DE)
DeviceNet
Network MAC ID
Sets the function to see the actual DeviceNet MAC address using
the keypad. This parameter functions as a monitor only.
0
(0 - 63)
853
