YASKAWA GA700 - Page 86

2.12 Main Circuit Wiring
86 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
Model Terminals
Recommended
Gauge
mm
2
Applicable
Gauge
(IP20
Applicable
Gauge
*1
)
mm
2
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening
Torque
N∙m (lb.∙in.)
Size Shape
2110
R/L1, S/L2, T/L3 35
16 - 35
(25 - 35)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
U/T1, V/T2, W/T3 35
16 - 35
(25 - 35)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
-, +1 50
25 - 50
(25 - 50)
27 M8
Hex socket cap
(WAF: 6 mm)
10 - 12
(89 - 107)
B1, B2 25
6 - 25
(6 - 25)
21 M6 Minus (-)
3 - 3.5
(27 - 31)
16
16 - 25
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
2138
R/L1, S/L2, T/L3 50
16 - 50
(50)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
U/T1, V/T2, W/T3 50
16 - 50
(50)
27 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
-, +1 70
25 - 70
(50 - 70)
27 M8
Hex socket cap
(WAF: 6 mm)
10 - 12
(89 - 107)
B1, B2 35
6 - 35
(6 - 35)
21 M6 Minus (-)
3 - 3.5
(27 - 31)
25
25
(-)
- M6 Hex bolt (+)
5.4 - 6.0
(47.8 - 53.1)
2169
R/L1, S/L2, T/L3 70
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
U/T1, V/T2, W/T3 70
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
-, -, +1, +1
*5 *6
35
16 - 50
(50)
28 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
+3
*6
50
25 - 70
(50 - 70)
28 M8
Hex socket cap
(WAF: 6 mm)
8 - 9
(71 - 80)
35
25 - 50
(-)
- M8 Hex bolt (slotted)
9.0 - 11
(79.7 - 97.4)
2211
R/L1, S/L2, T/L3 95
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
U/T1, V/T2, W/T3 95
50 - 95
(95)
37 M10
Hex socket cap
(WAF: 8 mm)
12 - 14
(107 - 124)
-, -, +1, +1
*5 *6
50
16 - 50
(50)
28 M6
Hex socket cap
(WAF: 5 mm)
8 - 9
(71 - 80)
+3
*6
70
25 - 70
(50 - 70)
28 M8
Hex socket cap
(WAF: 6 mm)
8 - 9
(71 - 80)
50
25 - 50
(-)
- M8 Hex bolt (slotted)
9.0 - 11
(79.7 - 97.4)
