Zebra ZM400 Series User Manual

Corrective Maintenance
Printhead Latch
192
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Printhead Latch
Tools Required
Remove the Old Latch
1.
2.
Tools • You need these tools to complete this procedure:
 Phillips Screwdriver Set
 Flat-blade Screwdriver Set
 Safety Glasses
 Adjustable Wrench
 Metric Nutdriver Set
 Metric Hex Key (Allen Wrench) Set
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
See Figure 66. Open the media door and remove the media and ribbon.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
