Corrective Maintenance
Printhead Conversion
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Printhead Conversion
Tools Required
Remove the Electronics Cover
1.
2.
Caution • A qualified service technician must perform this installation.
Note • For optimal printing quality and proper printer performance across our product line,
Zebra strongly recommends the use of genuine Zebra™ supplies as part of the total solution.
Specifically, the ZM400 and ZM600 are designed to work only with genuine Zebra™
printheads, thus maximizing safety and print quality.
Tools • You need these tools to complete this procedure:
 Phillips Screwdriver Set
 Metric Hex Key (Allen wrench) Set
 Antistatic Wriststrap
 Metric Nutdriver Set
 47362* Zebra Preventive Maintenance
Kit
* In place of the Preventive Maintenance Kit, you may use clean swabs and a solution containing
isopropyl alcohol (≥ 90%) with deionized water (≤10%).
Note • Retain all parts removed during disassembly, unless otherwise directed.
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media cover and remove the media and ribbon.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
