Corrective Maintenance
232
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Adjust the Sensor Gap
1. Which model printer are you working on?
If you have a… Then…
ZM400 a. See Figure 100. Using a hex key, loosen the mounting screw
securing the upper media sensor to the mounting shaft one full
turn.
b. Insert the gapping shim supplied in the kit between the upper and
lower media sensors at the notch.
c. Lightly squeeze the upper and lower sensors together and then
tighten the mounting screw.
d. Remove the gapping shim.
ZM600
a. See Figure 101. Using a hex key, loosen the two mounting
screws securing the upper media sensor to the mounting shaft
one full turn.
b. Insert the gapping shim supplied in the kit between the upper and
lower media sensors between the two notches.
c. Lightly squeeze the upper and lower sensors together and then
tighten the mounting screws.
d. Remove the gapping shim.
