Corrective Maintenance
Media Cover
426
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Media Cover
Tools Required
Remove the Old Media Door
1.
Turn off (O) the printer and disconnect the AC power cord and all data cables.
2.
Tools • You need these tools to complete this procedure:
Metric Nutdriver Set
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media cover and remove the media and ribbon.
To Next Page
