427
Corrective Maintenance
Media Cover
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
3. See Figure 284. Remove the four screws and lock washers securing the old door and lift
the door off of the printer.
Figure 284 • Media Door
1
Media door
2
External lock washers (4)
3
Mounting screws (4)
1
2
3
