Corrective Maintenance
Media Cover
428
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Install the New Media Door
1. See Figure 284 on page 427. Install the new door by aligning the front hinge with the front
hole and installing the mounting screw and lock washer.
2. Install the other three screws and lock washers supplied in the kit. Ensure the door is
aligned properly and reinstall media and ribbon.
3.
4.
Reinstall the AC power cord and all data cables.
5. Turn on (l) the printer.
Note • The front hole is a locating hole; install this screw and lock washer first.
Caution • When you are loading media or ribbon, remove all jewelry that could come
into contact with the printhead or other printer parts.
Reinstall the media and ribbon.
