Zebra ZM400 Series

31
System Description
Printer Media Compartment
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Printer Media Compartment
Figure 4 shows the components inside the media compartment of your printer. Depending on
installed options, your printer may look slightly different.
Figure 4 • Printer Components
Note • For optimal printing quality and proper printer performance across our product line,
Zebra strongly recommends the use of genuine Zebra™ supplies as part of the total solution.
Specifically, the ZM400 and ZM600 are designed to work only with genuine Zebra™
printheads, thus maximizing safety and print quality.
1
Printhead assembly
6
Ribbon take-up spindle
2
Control panel
7
Ribbon supply spindle
3
Media door
8
Dancer assembly
4
Media supply guide
9
Printhead release latch
5
Media supply hanger
9
4
5
6
7
1
2
3
8
