Corrective Maintenance
Platen Coupling
368
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Platen Coupling
Tools Required
Remove the Electronics Cover
1.
Tools • You need these tools to complete this procedure:
Phillips Screwdriver Set
Metric Nutdriver Set
Flat-blade Screwdriver Set
Bent Tip Scribe or a tool with a small
hook
Metric Hex Key (Allen wrench) Set
Safety Glasses
Needle Nose Pliers
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
