Zebra ZM400 Series User Manual

77
Operations
Control Panel Parameters
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Control Panel Parameters
Use the LCD on the control panel to view and adjust printer settings.
How to View or Modify Parameters
While viewing parameters, press PLUS (+) to continue to the next parameter, or press
MINUS (-) to return to the previous parameter in the cycle. Press SELECT when you want to
modify a parameter or view its options. When a parameter is changed, an asterisk (*) appears
in the upper left corner of the display to indicate that the value is different from the one
currently active in the printer.
Additional Parameters
Additional parameters appear in the following situations.
• When a wired print server is installed in the printer. For more information, refer to the
ZebraNet 10/100 Print Server User and Reference Guide
• When a wireless print server is installed in the printer. Refer to the ZebraNet Wireless
Print Server and Wireless Plus Print Server User Guide.
• When a Radio Frequency Identification (RFID) reader is installed. Refer to the RFID
Programming Guide for more information.
Copies of these manuals are available at http://www.zebra.com/manuals or on the user CD that
came with your printer.
Note • Your label preparation software or the printer driver may override adjustments made
through the control panel. Refer to the software or driver documentation for more
information.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
