Zebra ZM400 Series User Manual

Corrective Maintenance
Pinch Roller
382
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Pinch Roller
Tools Required
Remove the Pinch Roller
1.
Turn off (O) the printer and disconnect the AC power cord and all data cables.
2.
3.
See Figure 244. Lower the pinch roller holder assembly to the open position.
Tools • You need these tools to complete this procedure:
 Flat-blade Screwdriver Set
 Metric Hex Key (Allen Wrench) Set
 Safety Goggles
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media door and remove media and ribbon from the printer.
