Zebra ZM400 Series User Manual

321
Corrective Maintenance
Static Brush
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Static Brush
This procedure is for installing the static brush assembly in the printer. Read these instructions
thoroughly before performing this procedure.
This kit includes the parts and documentation necessary to install the static brush assembly in
the following printers:
•ZM400™
•ZM600™
Read these instructions thoroughly before attempting to install this kit.
Prepare for Installation
Parts List
Figure 184 • Kit Contents
Table 22 • Kit Parts List
3 Item Qty Part Number Description
1
1
79854M
ZM400 Static Brush Maintenance Kit
2
1
79855M
ZM600 Static Brush Maintenance Kit
Bold = Part available for purchase.
Italic = Part not available for purchase, listed and shown for reference only.
2
1

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
