Zebra ZM400 Series

Corrective Maintenance
Cutter Option
328
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Remove the Front Cover
1. See Figure 190. Remove the front cover by pulling out on the upper left and right corners.
Figure 190 • Remove the Front Cover
2. Lift the front cover to remove it.
3. Close the media door.
1
Front cover
2
Mounting hooks
1
2
