Corrective Maintenance
Magnetic Printhead Latch
206
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Magnetic Printhead Latch
Tools Required
Remove the Electronics Cover
1.
2.
Tools • You need these tools to complete this procedure:
Phillips Screwdriver Set
Flat Blade Screwdriver Set
Needle Nose Pliers
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Turn off (O) the printer and disconnect the AC power cord and all data cables.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Remove the media and ribbon.
