Zebra ZM400 Series User Manual

205
Corrective Maintenance
Printhead Pressure Dials
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
9. Lift and hold the printhead in position while securing it with the previously removed
thumbscrew and then close the print mechanism.
10. Set the printer up on the base.
11. Open the print mechanism and latch it in the open position.
12.
Using the Zebra Preventive Maintenance Kit, clean the printhead and platen roller.
13. Reinstall media.
14. See Figure 71 on page 200. Rotate the two printhead pressure dials to the desired position
for your daily printing.
15. Close the media door.
16. Reconnect the AC power cord and data cables.
17. Turn on (l) the printer.
Caution • Do not use sharp objects to clean the printhead or platen roller.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
