Zebra ZM400 Series User Manual

235
Corrective Maintenance
Ribbon/Head Open Sensor Assembly
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Ribbon/Head Open Sensor Assembly
Tools Required
Remove the Electronics Cover
1.
2.
Tools • You need these tools to complete this procedure:
 Phillips Screwdriver Set
 Metric Nutdriver Set
 Antistatic Wriststrap and Mat
 Metric and inch Feeler Gauges; must
include: 1.5 mm (0.060 in.)
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media door and remove the media and ribbon.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
