Corrective Maintenance
Ribbon Take-up Spindle
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Ribbon Take-up Spindle
Tools Required
Remove the Electronic Cover
1.
2.
Caution • A qualified service technician must perform this installation.
Tools • You need these tools to complete this procedure:
Phillips Screwdriver Set
Metric Hex Key (Allen Wrench) Set
Metric Nutdriver Set
Antistatic Wriststrap and Mat
Metric Feeler Gauges; must include:
0.5 mm
Caution • Turn off (O) the printer and disconnect it from the power source before
performing the following procedure.
Caution • While performing any tasks near an open printhead, remove all rings,
watches, hanging necklaces, identification badges, or other metallic objects that could
touch the printhead.
Open the media cover and remove the media and ribbon.
