Corrective Maintenance
Cutter Option
8/9/07
ZM400/ZM600 Maintenance Manual
14207L-001 A
5.
See
Figure
188
. Remove the four mo
unting scre
ws on the rear of the printer
.
Figure 188 • Remove the Electronics Cover Mount
ing Screws
6.
See
Figu
re
189
. Re
move the electronics cove
r by pressi
ng
in on the ele
ctronics cove
r with
the palm of your hand, and then lif
ting up on the cover
.
Figure 189 • Remove the Electronics Cover
1
Electronics cover
2
Mounting screws
(4)
2
1
2
1
326
328
